8 Ton Small Crawler and Wheel Driven Excavator - Xiniu X9 | Renco Industrial

Home Renco Industrial Construction Equipment Excavators8 Ton Small Crawler and Wheel Driven Excavator – Xiniu X9

8 Ton Small Crawler and Wheel Driven Excavator – Xiniu X9

8 Ton Small Crawler and Wheel Driven Excavator – Xiniu X9

8 Ton Small Crawler and Wheel Driven Excavator – Xiniu X9

8 Ton Small Crawler and Wheel Driven Excavator – Xiniu X9

8 Ton Small Crawler and Wheel Driven Excavator – Xiniu X9

8 Ton Small Crawler and Wheel Driven Excavator – Xiniu X9

8 Ton Small Crawler and Wheel Driven Excavator – Xiniu X9

8 Ton Small Crawler and Wheel Driven Excavator – Xiniu X9

8 Ton Small Crawler and Wheel Driven Excavator – Xiniu X9

R950,000.00

SKU: RN3TLY2-1 Categories: Construction Equipment, Excavators, Mining Equipment

Additional information

Model	Xiniu X9
Condition	New
Type	Excavator
Applicable Industries	Manufacturing Plant, Farms, Home Use, Retail, Construction works , Energy & Mining
Hydraulic Cylinder Brand	XINCHAI
Hydraulic Pump Brand	XINCHAI
Hydraulic Valve Brand	XINCHAI
Warranty of core components	2 Years
Core Components	Engine, Gear, Motor, Gearbox, Hydraulic Pump, Hydraulic Cylinder, Hydraulic Valve.
Total length (Boom3.6m+Bucket arm 2m	6570 mm
Total height (Boom3.6m+Bucket arm 2m	2982 mm
Counter weight turning radius	1836 mm
Engine hood height	2104 mm
Counter weight ground clearance	1120 mm
Upper structure width	2000 mm
Cabin height (wheels up	2982 mm
Tire width	2120 mm
Ground clearance	270 mm
Wheels up wheel gauge	3400 mm
Distance of swing center to rear wheel (wheels up)	1682 mm
Wheels down wheel gauge	3510 mm
Distance of swing center to rear wheel (wheels down)	1760 mm
Rear wheel ground clearance(wheel up)	300 mm
Tracks ground clearance(wheel down)	310 mm
Total height (wheels down)	3190 mm
Track wheel track	2020 mm
Track width	400 mm
Track outer width	2160 mm
Technical performance specification	———–
Total weight	8003kg
Bucket capacity	0.3m3
Engine Model	YANMAR 3TNV94L-BNBKC
Engine Displacement	3.00L
Engine power/rpm	33.7KW/2100RPM
Engine Max. torque	193.2-210.6 N.m/126±100rpm
Wheel travelling speed	25 km/h
Track travelling speed	2.3km/h
Swing speed	9rpm
Max. grade ability	30°
Hydraulic system	Rexroth from Germany
Pump	Variable capacity pump
Pressure	25 Mpa
Displacement	132 L/min
Hydraulic Tank Capacit	175 L
Capacity of fuel tank	150 L
Engine oil capacity	12 L
Working device	Boom 3.5m+Arm 2m
Max. digging radius	6880mm
Max. digging radius (on ground)	6735mm
Max. digging depth	7130mm
Max. dumping height	5220mm
Min. turning radius	2617mm
Max. vertical digging depth	3425mm
Bucket digging force (KN)	56KN
Bucket arm digging force (KN)	36KN
After-sales Service Provided	Online support/ on site support / parts replacement
After Sale Support Provided	Yes
Warranty	2 Years
